Key specifications

• Power

• Input: 150 to 285 VAC at 47 Hz to 63 Hz.

• Output: 12 VDC at 1 A per channel (maximum).

• Total power: 48 W.

• Cable length compensation: The output voltage can be adjusted to compensate for voltage drop over long cable runs:

• Normal: 12 VDC

• Long: 13.5 VDC

• Ex-Long: 15 VDC

• Protection: Includes over-current, short-circuit, and over-voltage protection.

• Physical and environmental

• Dimensions: 144 mm × 80 mm × 33 mm.

• Weight: Approximately 158g (for a similar model, DS-2FA1202-B).

• Color: White.

• Operating conditions:

• Temperature: 0°C to 40°C.

• Humidity: 10% to 95% (non-condensing).

Storage conditions:

• Temperature: -40°C to 80°C.

• Humidity: 5% to 95% (non-condensing).

Features

• 4 independent channels: Each channel provides a separate 12V DC output, which is useful for powering up to four surveillance cameras.

• Good EMC performance: This refers to the device's electromagnetic compatibility, meaning it is designed to function well in its environment without causing or being affected by electromagnetic interference.

• Compact size: The small form factor makes it suitable for camera applications.

• LED indicator: A green LED provides a visual indication of the power status.

• Grid terminal output: The DC output uses a grid terminal (DC plug) for connections.

• Wide voltage input: The broad input voltage range (150 to 285 VAC) makes it adaptable to different power sources.
