Video and performance

• Supports 4 IP video inputs with resolutions up to 6MP.

• Offers recording resolutions from 6MP down to QCIF.

• Decoding capability allows for playback of up to 4 channels at 1080p or 2 channels at 4MP.

• Has an incoming bandwidth of 40 Mbps and an outgoing bandwidth of 60 Mbps.

• Utilizes H.265+ / H.265 / H.264+ / H.264 video compression, with H.265+ helping to reduce storage and bandwidth needs.

• Includes HDMI and VGA outputs supporting resolutions up to 1920 × 1080p, with simultaneous display capability.

Audio and playback

• Does not have dedicated audio input/output, relying on audio from IP cameras.

• Supports synchronous playback of 4 channels.

• Features smart search and playback functions.

Storage and external interfaces

• Equipped with 1 SATA interface supporting a single HDD up to 6TB.

• Has 2 USB 2.0 ports on the rear.

Network and PoE

• Features 4 PoE interfaces (RJ-45 10/100 Mbps) with a total power budget of ≤W36 and is compliant with IEEE 802.3 af/at standards.

• Includes 1 network interface (RJ-45 10/100 Mbps).

• Allows for mobile viewing and network management via the HiLookVision app.
