Video and performance

• Video compression: H.265+, H.265, H.264+, and H.264.

• IP video input: Up to 8 channels.

• Incoming bandwidth: 60 Mbps.

• Recording resolution: Up to 4 MP on all channels.

• Decoding capability:

  • 4-ch @ 1080p (25 fps)

  • 2-ch @ 4 MP (25 fps)

• Video outputs: Simultaneous HDMI and VGA output for connecting to a monitor.

• Playback resolution:

  • 2-ch @ 4 MP

  • 4-ch @ 1080p

Storage and connectivity

• HDD interface: One SATA interface for installing an internal hard disk drive.

• Max HDD capacity: Up to 6 TB.

• Network interface: One RJ-45 10/100 Mbps self-adaptive Ethernet port.

• USB interface: Two USB 2.0 ports on the rear panel.

• Remote connection: Supports up to 16 remote connections.

• Network protocols: TCP/IP, DHCP, HiLookVision, DNS, DDNS, NTP, SADP, SMTP, and UPnP.

Smart features

• Intrusion and line crossing detection: Can be used with compatible cameras for smart event detection.

• Smart search and playback: Allows users to find specific events more efficiently.

• Automatic camera discovery: Automatically finds and adds new network cameras to the system.

• Remote management: Uses the HiLookVision platform for remote network management and viewing.
