Key specifications

Model: THC-B129-P
Image sensor: 2 MP CMOS
Maximum resolution: 1920 x 1080
Lens: Fixed focal lens options of 2.8 mm or 3.6 mm. Some retailers also list a 6 mm option.
- Field of view (2.8 mm):
  102∘102 raised to the composed with power
  102∘
  (horizontal),
  54∘54 raised to the composed with power
  54∘
  (vertical),
  121∘121 raised to the composed with power
  121∘
  (diagonal)
- Field of view (3.6 mm):
  80∘80 raised to the composed with power
  80∘
  (horizontal),
  43∘43 raised to the composed with power
  43∘
  (vertical),
  95∘95 raised to the composed with power
  95∘
  (diagonal)
Minimum illumination: 0.001 Lux @ (F1.0, AGC ON). It can achieve 0 Lux with the included white light.
Night imaging: Provides up to 20 meters of bright night imaging using its supplementary white light.
Video output: One port that can switch between four analog signals: TVI, AHD, CVI, and CVBS.
Wide Dynamic Range (WDR): Digital WDR to balance brightness in high-contrast scenes.
Noise reduction: 3D DNR (Digital Noise Reduction) for clean, sharp images.
Weatherproof rating: IP66, making it dust-tight and resistant to powerful water jets.
Operating conditions: Can function in temperatures from
-40∘Cnegative 40 raised to the composed with power cap C
−40∘𝐶
to
60∘C60 raised to the composed with power cap C
60∘𝐶
and humidity of up to 90%.
Material: Plastic
Dimensions: 162.7 mm x 70 mm x 70 mm
Power requirements: 12 VDC ± 25%, with a maximum power consumption of 2.4 W.
